    Bharat Machine Flat back 18-10 f ch

    Bharat Machine Flat back 18-10 f ch
    Bharat Machine Flat back 18-10 f ch
    Product Code : 01
    Product Description

    Features:

    • Mounted on iron stand
    • with bed made of steel
    • with hardened and grinded cams
    • with arrangement to increase / decrease stitch length
    • with timing belt system
    • with motorized racking system
    • with german bushes in carriage
    • with electric motor and driving attachment with drive

    Technical Specifications:

    Model

    BMF-11

    Gauge

    6gg,7gg,8gg,9gg,10gg, 11gg, 12gg, 13gg 14gg

    Bed width

    28 '' on wards up to 72''(inches)

    Speed

    1.2 m courses/ max (knitting became different with knitting width and knitting condition.)

    Yarn feeders

    4 feeders on 2 rails (6 and 8 feeders optional )

    Cam system

    Tuck, miss, knit on front and rear bed

    needle

    High and low butt needle.

    Stitch density

    8 positions on front and rear bed

    Racking

    Motorized racking 1 to 5 from right to left and back to home position

    Driving system

    Timing belt system for carriage.

    Take down

    Roller divided into group of take down .

    Stop motion

    Yarn break, knot yarn guage, fabric drop, needle break, piece count, motor overload/low voltage.

    Display

    20 x 4 line LCD,, use friendly programming on machine in english

    Control system

    Micro computer system.it operators from the same location in case of power failure

    Ac drive

    1 HP AC drive (variable frequency drive)

    Motor

    1 HP or .75 kw motor (Three phase 220v)
